Main Features

• Main stream supports encoding at up to WD1 resolution in real time and sub stream at CIF/QCIF resolution.
• Simultaneous HDMI, VGA and CVBS outputs.
• HDMI output and VGA output at up to 1920×1080P resolution.
• Channel-zero encoding.
• Support dual stream.
• HDD quota management; different capacity can be assigned to different channel.
• Holiday recording schedule configuration.
• Smart searching for the event triggered record files.
• Digital zoom of video in live view or playback mode.
• Up to 4/8/16-ch synchronous playback.
• 1 self-adaptive 10M/100M network interface.
• IPv6 is supported.
• Network detection function.
• NTP, SMTP, NFS, UPnP™ and iSCSI protocols supported.

Functions & Performances

Compression :

• PAL/NTSC adaptive video inputs.
• H.264 video compression with high reliability and superior definition.
• Each channel supports dual-stream.
• Main stream supports encoding at up to WD1 resolution in real time and sub stream at CIF/QCIF resolution.
• Independent configuration for each channel, including resolution, frame rate, bit rate, image quality, etc.
• The quality of the input and output video is configurable.
• Normal and event recording parameters configurable for per individual camera.
• Encoding for both audio/video composite stream and video stream; audio and video synchronization during composite stream encoding.
• Watermark technology.

Local Monitoring :

• Simultaneous HDMI, VGA and CVBS outputs.
• HDMI/VGA output at up to 1920×1080P resolution.
• 1/4/6/8/9/16-division live view is supported, and the display sequence of screens is adjustable.
• Live view screen can be switched in group, and manual switch and automatic cycle review is also provided, the interval of automatic cycle can be adjusted.
• Quick setting menu is provided for live view.
• The selected live view channel can be shielded.
• Motion detection, tamper-proof, video exception and video loss alarm functions.
• Privacy mask.
• Several PTZ protocols supported; PTZ preset, patrol and pattern.
• Zooming in by clicking the mouse and PTZ tracing by dragging mouse.

Hard Disk Management :

• 1 SATA hard disk can be connected to DV-3104 and 2 SATA hard disks to DV-3108/3116, with a maximum of 4TB storage capacity for each disk.
• 8 network disks (8 NAS disks, or 7 NAS disks+1 IP SAN disk) can be connected.
• HDD group management.
• Support HDD standby function.
• HDD property: redundancy, read-only, read/write (R/W).
• HDD quota management; different capacity can be assigned to different channel.

Recording :

• Holiday recording schedule configuration.
• Normal and event video encoding parameters.
• Multiple recording types: manual, normal, and motion.
• 8 recording time periods with separated recording types.
• Pre-record and post-record for motion detection for recording, and prerecord time for schedule and manual recording.
• Searching record files by event.
• Customization of tags, searching and playing back by tags.
• Locking and unlocking record files.
• Local redundant recording.
• Searching and playing back record files by channel number, recording type, start time, end time, etc.
• Smart search for the selected area in the video.
• Zooming in when playback.
• Playing reversely.
• Supports pause, speed up, speed down, skip forward, and skip backward when playback, locating by dragging the mouse.
• Up to 4/8/16-ch synchronous playback.

Backup :

• Export video data by USB or SATA storage device.
• Export video clips when playback.
• Management and maintenance of backup devices.

Alarm & Exception :

• Alarm for video loss, motion detection, tampering, abnormal signal, video input/output standard mismatch, illegal login, network disconnected, IP confliction, abnormal record, HDD error, and HDD full, etc.
• Alarm event triggers full screen monitoring, audio alarm, notifying surveillance center and sending email.
• Automatic restore when system is abnormal.

Others :

• Operable by mouse, or IR remote control.
• Three-level user management; admin user is allowed to create many operating accounts and define their operating permission, which s the limit to access any channel.
• Operation, exceptions and log recording and searching.
• Import and export of device configuration information.

Network :

• 1 self-adaptive 10M/100M network interface.
• IPv6 is supported.
• TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, UPnP™, NFS, and iSCSI are supported.
• TCP, UDP and RTP for unicast.
• Remote search, playback, download, locking and unlocking the record files, and downloading files broken transfer resume.
• Remote parameters setup; remote import/export of device parameters.
• Remote viewing of the device status, system logs and alarm status.
• Remote locking and unlocking of control panel and mouse.
• Remote HDD formatting and program upgrading.
• Remote system restart.
• RS-485 transparent channel transmission.
• Alarm event and exception information can be sent to the remote host.
• Remotely start/stop recording.
• Upgrade by remote FTP server.
• Remote PTZ control.
• Two-way audio and voice broadcasting.
• Embedded WEB server.

Development :

• SDK for Windows and Linux system.
• Source code of application software for demo.
• Development support and training for application system.
